DC 12V 24V 6A Automatic Adjust PIR Motion Sensor Switch Module

DC 12V 24V 6A Automatic Adjust PIR Motion Sensor Switch Module

The DC 12V 24V 6A Automatic Adjust PIR Motion Sensor Switch Module is an intelligent control device designed for LED strip lights and lamps. Crafted from high-quality polymer materials, it offers an economical and versatile solution for various indoor lighting applications.

Automatic Sensing: This module features highly sensitive motion detection, automatically turning LED strip lights or lamps on or off when human activity is detected.
Wide Voltage Range: Compatible with power supplies ranging from DC 12V to 24V, making it suitable for various types of power systems.
Adjustable Functionality: Users can adjust the sensing distance and angle to meet the requirements of different lighting scenarios.
Delay Setting: Customizable delay times, ranging from 1 to 10 minutes, allow users to fine-tune the module's response.
High Output Capacity: Supports a maximum output current of 6A, enabling control of LED lighting devices with power ratings of up to 144W.
Technical Specifications:


Colors: Black
Detection Distance: 8 meters
Detection Angle: 120 degrees
Delay Time: 1-10 minutes
Control Distance: 8 meters

The DC 12V 24V 6A Automatic Adjust PIR Motion Sensor Switch Module is a straightforward and practical solution to enhance lighting systems' efficiency, reduce energy consumption, and provide users with convenient lighting control. Whether for home illumination or commercial applications, it is a reliable choice.
